QSFP-100G-CWDM4-S Compatible 100GBASE-CWDM4 QSFP28 1310nm 2km DOM 10-3145-01 Transceiver Module

The original switches marked “Unique” below could be found at Topstar, eg: Juniper MX960 & EX 4300 series, Nexus 9396PX & ASR 9000 Series, HP 5900 Series & HP 5406R ZL2 V3(J9996A), Arista 7050S-64, Brocade ICX7750-26Q & ICX6610-48, Avaya VSP 7000 MDA 2, etc.
  • item no.:

    QSFP-100G-CWDM
  • Warranty:

    1 Year
  • Temperature:

    0 to 70°C
  • Data Rate:

    100G
  • Distance:

    2km
  • Wavelength:

    1271nm, 1291nm, 1311nm and 1331nm
  • Connector:

    LC duplex
product details

QSFP-100G-CWDM4-S Compatible 100GBASE-CWDM4 QSFP28 1310nm 2km DOM 10-3145-01 Transceiver Module


Features


  • 4 channels   full-duplex  transceiver  modules
  • Transmission  data rate up to 26Gbps per  channel
  • 4 x 26Gb/s DFB-based CWDM uncooled  transmitter
  • 4 channels   PIN ROSA
  • Internal CDR circuits on both receiver and transmitter channels
  • Low power consumption  <3.5W
  • Hot Pluggable   QSFP form factor
  • Up to reach 2km for  G.652 SMF[with  KR4 FEC]
  • Duplex  LC receptacles
  • Built- in  digital  diagnostic  functions
  • Operating  case temperature  0°C to +70°C
  • 3.3V power supply  voltage
  • RoHS 6 compliant(lead  free)
