GLC-FE-100EX Compatible 100BASE-EX SFP 1310nm 40km DOM Transceiver Module

For Cisco
new products

GLC-FE-100EX
GLC-FE-100EX

GLC-FE-100EX Compatible 100BASE-EX SFP 1310nm 40km DOM Transceiver Module

GLC-FE-100EX Compatible 100BASE-EX SFP 1310nm 40km DOM Transceiver Module is supported on a wide range of  equipment.

  • item no.:

    GLC-FE-100EX

  • brand:

    Top-Trans

  • Warranty:

    1 Year

  • Temperature:

    0 to 70°C

  • Data Rate:

    155M

  • Distance:

    40km

  • Wavelength:

    1310nm

  • Connector:

    LC duplex
contact now
Datasheet
product details

FE-100EX Compatible 100BASE-EX SFP 1310nm 40km DOM Transceiver Module

Features



  • Transceiver unit with independent
  • 1310nmFP Laser diode transmitter
  • In GaAs PIN photo diode receiver
  • Up to 155Mbps data rate operation
  • Up to 40KM on 9/125μmSMF
  • Standard serial ID information compliant with SFPMSA
  • Digital Diagnostic Monitor Interface
  • Very low EMI and excellent ESD protection
  • +3.3V single power supply
  • RoHS compliant
  • Case operating temperature Commercial:0°Cto +70°C Extended:-10°Cto +80°C Industrial:-40°Cto+85°C

Compatible with


  • 1900 Series Integrated Services Router - EHWIC-1GE-SFP-CU
  • ME 6500 Series - ME-C6524GT-8S
  • IE2000 Series - IE-2000-4TS-L
  • IE2000 Series - IE-2000-16TC-G-L
  • Catalyst 4500 Series Switch - WS-X4248-FE-SFP
  • Catalyst 2960 Series - WS-C2960-48TC-L
  • Catalyst Express 500 - WS-CE500-24PC
  • 7600 Series Router - WS-X6148-FE-SFP
  • IE2000 Series - IE-2000-16TC-G-N
  • IE2000 Series - IE-2000-16TC-B
  • Catalyst 2960-S Series - WS-C2960S-48LPS-L
  • 2000 Connected Grid Router Series - CGR 2010
  • IE2000 Series - IE-2000-4TS-B
  • Catalyst Express 520 - WS-CE520-24PC-K9
  • Catalyst 2960-S Series - WS-C2960S-24PS-L
  • IE3010 Series Switch - IE-3010-16S-8PC
  • 2500 Connected Grid Switch Series - CGS-2520-16S-8PC
  • Catalyst 2960 Series - WS-C2960G-48TC-L
  • 3900 Series Integrated Services Router - Cisco 3945
  • Catalyst 2960-C Series - WS-C2960C-8TC-S
  • ME 3400 - ME-3400G-2CS-A
  • Catalyst 3560 Series - WS-C3560-12PC-S
  • 2900 Series Integrated Services Router - HWIC-1GE-SFP
  • ME 3400 - ME-3400EG-2CS-A
  • Catalyst 2960 Series - WS-C2960-24PC-L
  • Catalyst Express 520 - WS-CE520G-24TC-K9
  • Catalyst 2960-S Series - WS-C2960S-48FPS-L
  • Catalyst 2960 Series - WS-C2960G-24TC-L
  • ME 3400 - ME-3400G-12CS-A
  • Catalyst Express 520 - WS-CE520-24LC-K9
  • Catalyst 2960-C Series - WS-C2960CG-8TC-L
  • Catalyst 2960-C Series - WS-C2960C-12PC-L
  • ME 3400 - ME-3400-24CS-A
  • Catalyst 2960-X Series - WS-C2960X-18TS-LL
  • IE2000 Series - IE-2000-8TC-B
  • Catalyst 3560-C Series - WS-C3560C-12PC-S
  • Catalyst 2960-C Series - WS-C2960C-8PC-L
  • Catalyst 2960 Series - WS-C2960-8TC-L
  • ME 3800X - ME-3800X-24FS-M (client ports)
  • ME 3600X - ME-3600X-24FS-M (client ports)
  • IE2000 Series - IE-2000-16TC-G-X
  • Catalyst 2960 Series - WS-C2960-48PST-L
  • 1941 Series Router HWC-1GE-SFP
  • Catalyst 2960-S Series - WS-C2960S-48TS-L
  • Catalyst 3560-C Series - WS-C3560CG-8TC-S
  • 3900 Series Integrated Services Router - Cisco 3925E
  • Catalyst 2960+ Series - WS-C2960+24TC-L
  • Catalyst 3560-C Series - WS-C3560C-8PC-S
  • 2500 Connected Grid Switch Series - CGS-2520-24TC
  • IE3000 Series Switch - IE-3000-4TC
  • ME 3400 - ME-3400-24FS-A
  • Catalyst Express 500 - WS-CE500-12TC
  • Catalyst 3560 Series - WS-C3560-8PC-S
  • ME 2400 - ME-2400-24TS-D
  • ME 2400 - ME-2400-24TS-A
  • Catalyst 2960-S Series - WS-C2960S-24TS-L
  • ME 3400 - ME-3400E-24TS-M
  • ME 6500 Series - ME-C6524GS-8S
  • Catalyst 3750 Series
  • 1921 Series Router EHWC-1GE-SFP-CU
  • IE2000 Series - IE-2000-16TC-G-E
  • ME 3400 - ME-3400-24TS-A
  • IE2000 Series - IE-2000-16TC-L
  • Catalyst Express 520 - WS-CE520-8PC-K9
  • 892F Series Wireless Integrated Services Router - CISCO892FW-K9
  • 892F Series Wireless Integrated Services Router - CISCO892F-K9
  • Catalyst 6500 Series - WS-X6148-FE-SFP
  • Catalyst 2960+ Series - WS-C2960+48PST-L
  • 3900 Series Integrated Services Router - Cisco 3945E
  • Catalyst 2960 Series - WS-C2960-24TC-L
  • ME 3400 - ME-3400EG-12CS-M
  • Catalyst 4948-E Series - WS-X4993
  • Catalyst Express 500 - WS-CE500-24LC
  • ME 3400 - ME-3400-24TS-D
  • Catalyst 3560-C Series - WS-C3560CG-8PC-S
  • Catalyst Express 500 - WS-CE500G-12TC
  • ME 3400 - ME-3400G-12CS-D
  • IE2000 Series - IE-2000-8TC-L
  • Catalyst 2960 Series - WS-C2960G-8TC-L






tags : GLC-FE-100EX SFP-155M 155M 1310nm 40km 155M 40km SFP 1310nm 40km SFP-155M 40km
