GLC-BX-20U Compatible 1000BASE-BX BiDi SFP 1310nm-TX/1550nm-RX 20km DOM Transceiver Module

GLC-BX-20U Compatible 1000BASE-BX SFP Transceiver Module (SMF, 1310nm-TX/1550nm-RX, 20km, LC, DOM)
  • item no.:

    GLC-BX-20U
  • Warranty:

    1 Year
  • Temperature:

    0 to 70°C
  • Data Rate:

    155M
  • Distance:

    20km
  • Wavelength:

    155M Tx1310/Rx1550nm
  • Connector:

    LC simplex
product details

GLC-BX-20U Compatible 1000BASE-BX BiDi SFP 1310nm-TX/1550nm-RX 20km DOM Transceiver Module

Features



  • Transceiver unit with independent
  •  FP laser transmitter and PIN photo-detector
  •   Dual Data-rate of 1.25Gbps/1.0625Gbps Operation
  •  Up to 20KM transmission distance on 9/125μm SMF
  •  Standard serial ID information compliant with SFP MSA
  •  SFP MSA package  with duplex LC connector
  •  Digital Diagnostic Monitor Interface
  •  Very low EMI and excellent ESD protection
  •   +3.3V single power supply
  •   Wide operating temperature range
  •   RoHS compliant
  •  Case operating temperature Commercial: 0°C to +70°C Extended: -10°C to +80°C Industrial: -40°C to +85°C
