item no.:
40G QSFP LC 10kmWarranty:
1 YearCondition:
NewTemperature:
0 to 70°CData Rate:
44.6GbpsDistance:
10kmWavelength:
1310nmConnector:
LC
| Compatible | QSFP-40G-LR4 | Vendor Name | FS |
| Form Type | QSFP+ | Max Data Rate | 44.6Gbps |
| Wavelength | 1310nm | Max Cable Distance* | 10km |
| Connector | LC duplex | Transimitter Type | DFB CWDM |
| Cable Type | SMF | DDM/DOM Support | Yes |
| CDR | Supported | Protocols | OTN OTU3, 40G Ethernet, Infiniband, FiberChannel, SATA/SAS3, MSA Compliant |
| TX Power | -7~2.3dBm | Receiver Sensitivity | <-13.7dBm |
| Commercial Temperature Range | 0 to 70°C (32 to 158°F) |
prev :
Compatible QSFP-40G-SR-BD 10-2945-02 832nm - 918nm LC duplex fiber optics modulesnext :
QSFP-40G-LR4 Compatible 40GBASE-LR4 and OTU3 QSFP+ 1310nm 10km LC DOM Transceiver Module
Compatible Asa CWDM Fiber 10G 1270~1610nm 40km GBIC Module
This SFP+ ER CWDM transceiver is designed to transmit and receive optical data over single mode optical fiber for link length 40km. The transceiver consists of two sections: The transmitter section incorporates a colded EML laser. And the receiver section consists of a PIN photodiode integrated with a TIA. All modules satisfy class I laser safety requirements. Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage.
Compatible CWDM 10G 1470~1610nm 80km SFP GBIC Ethernet Lan Cards
This SFP+ ZR CWDM transceiver is designed to transmit and receive optical data over single mode optical fiber for link length 80km. The transceiver consists of two sections: The transmitter section incorporates a colded EML laser. And the receiver section consists of a APD photodiode integrated with a TIA. All modules satisfy class I laser safety requirements. Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage.
QSFP-40G-SR4 Compatible 40GBASE-SR4 QSFP+ 850nm 150m 10-2072-03 Transceiver Module
The 40G SR4 supports distances compatible with 10GBASE-SR, which is 150m on multi-mode fiber. In addition the SR4 optic can support 4 individual 10G-SR connections using MTP Trunk cable and LC duplex cables for multi-mode fiber.
ONS-SI-100-FX Compatible 100BASE-FX SFP 1310nm 2km 10-2350-01 DOM Transceiver Module
ONS 15454 ML-Series Multirate Ethernet Card - 15454-ML-MR-10,Transceiver unit with independent,1310nmFP Laser diode transmitter
Compatible Finisar Juniper 10GBASE X2 1310nm 10km LR Transceiver Module
The X2 Module is a highly integrated, Serial optical transponder module for high-speed, 10Gbit/s data transmission applications. 4×3.125Gbps Ethernet Signal Input by XAUI Interface. An integrated Coder / Decoder and multiplexer / demultiplexer .
Compatible X2-10GB-LRM Compatible 10GBASE-LRM X2 1310nm 220m DOM Transceiver
The X2 10GBASE-LRM 1310nm 220M Module is a highly integrated, Serial optical transponder module for 10Gbit/s data transmission applications. 4×3.125Gbps Ethernet Signal Input by XAUI Interface. An integrated Coder / Decoder and multiplexer / demultiplexer .
Compatible X2-10GB-SR Compatible 10GBASE-SR X2 850nm 300m DOM Transceiver Module
The 10GBASE-SR 850nm X2 Module is a highly integrated, Serial optical transponder module for 10Gbit/s data transmission applications.
ONS-SE-100-FX Compatible 100BASE-FX SFP 1310nm 2km 10-2212-01 DOM Transceiver Module
ONS 15454 ML-SerIE2000 Series-IEs Multirate Ethernet Card- ML100-X-8, Transceiver unit with independent,1310nmFP Laser diode transmitter
