Compatible WTD SFP Transceiver 10G ITU Grid 1170-1610nm Switch DWDM 80km 15xx.xxnm

This SFP+ ZR DWDM transceiver is designed to transmit and receive optical data over single mode optical fiber for link length 80km. The transceiver consists of two sections: The transmitter section incorporates a colded EML laser. And the receiver section consists of a APD photodiode integrated with a TIA. All modules satisfy class I laser safety requirements. Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage.

  • item no.:

    TOP-SFP+-DWDM-ZR-XX
  • lead time:

    1-3 working days
  • product orgin:

    China
  • brand:

    Top-Trans
  • shipping port:

    Shenzhen
  • payment:

    EXW
  • price range:

    1-6/456$
  • Warranty:

    3 Years
  • Temperature:

    0℃~70℃/ -5℃~85℃/ -20℃~85℃
  • Data Rate:

    10G
  • Distance:

    80km
  • Wavelength:

    DWDM
product details

WTD SFP Transceiver 10G ITU Grid 1170-1610nm Switch DWDM 80km 15xx.xxnm

SFP Transceiver 10G DWDM 80km


PRODUCT FEATURES

●Compliant with SFF-8431,SFF-8432 and IEE802.3ae

●Suitable for use in 100GHz channel spacing DWDM systems

●Cooled EML transmitter and APD receiver

●Digital Diagnostic Monitor Interface

●Hot pluggable

●link length up to 80km

●10GBASE-ER, and 2G/4G/ 8G/10G Fiber Channel applications.

●Low power consumption

●Operating case temperature: 0 to 70 °C



APPLICATIONS

●10G Ethernet

●10G Fiber Channel


Quality Guarantee:

Top-trans SFP passed quality system verifications: CE, RoHS, FCC.


Fully testing in Error Detector/ Industrial Oven/ Agilent Oscilloscope/ Digitizer/ WaveRunner etc specialist testing equipment before shipment.


Warranty:

If cargoes have any problem, just provide related photos or DDM screen shot, we support 1 month unconditional return, 1 year replacement or repair. This warranty does not cover damage caused by accident, improper care, improper use, negligence, normal wear and tear, or the natural breakdown of colors and materials over extended time and use.


Compatibility:

Testing in Cisco/ Brocade/ Juniper/ Dell/ Arista/ HPE/ H3C etc devices to guarantee 100% compatible with your equipment.


Shipping:

1. International Express: DHL, FedEx, UPS, TNT and EMS or others according to customers.

2. Customers specifying freight forwarders or negotiable shipping methods!

3. Delivery Time: 1 working day after received payment.


Payment Terms:
1. Payment: T/T, Western Union, MoneyGram,HSBC, as well as Cash Payment

2. MOQ: 1pcs

3. Warranty : 1 year

4. Package Informations: According to quantity ,we can provide professional package, 10/20/36 pcs in one anti-static plastic box, retail package. We can also do as your requirement.
