Brocade XBR-G6MIDR12PTPOD-32G BR-MIDRMFEB-01-Z software license for HD-G620-24-32G switch
read moreThe Brocade G720 Switch is a Gen 7 switch with 64 ports in an ultra-dense 1U design. Delivering unmatched 64G performance and 50% lower latency compared to the previous generation,
read moreCompatible QDD-400G-ZRP-S 400G ZRP Optical Transceivers
read moreKit contains two SFP+ modules that can be used as a pair to achieve operating data rate up to 25 Gbps for distances up to 15km on a single optical cable. SFP/ SFP+/ SFP28
read moreKit contains two SFP+ modules that can be used as a pair to achieve operating data rate up to 25 Gbps for distances up to 15km on a single optical cable. SFP/ SFP+/ SFP28 Optical Transceivers
read more12/24 Ports Compatible Brocade BR6510 Gen 5 Fiber Channel 1U Switch BR6510-24-8G-R/BR6510-12-8GR/BR6510-24-8GR Fiber Optical Switch Suitable For 57-1000117-01/57-1000027-01/57-0000080-01/57-0000088-01/57-0000089-01/57-1000487-01/57-0000089-01/57-1000488-01/57-1000262-01/57-1000489-01/XBR-000458/XBR-000258/XBR-000499/XBR-000498
read moreitem no.:
Brocade 57-0000089-0brand:
BrocadeWarranty:
1 YearTemperature:
0°C ~ 70°CData Rate:
16GDistance:
10kmWavelength:
1310nmConnector:
LC duplex
BrocadeFC64-48
8G FC SFP+
Brocade Transceiver Support Matrix
Description
Manufacturing Part Number
Brocade Ordering Part Number
Brocade7X
BrocadeFC32-X7-48
BrocadeG720
BrocadeX6
BrocadeFC32-64
BrocadeFC32-48
BrocadeG630
BrocadeG620
BrocadeG610
BrocadeDCX8510
Brocade6520
Brocade6510
Brocade6505
64 FC SFP+
SWL
57-1000495-01
XBR-000462/XBR-000463(1-pack)
Gen 7 FC QSFP+
SWL
57-1000481-01
XBR-000420(1-pack)
SWL
57-1000117-01
XBR-000163/XBR-000164(8-pack)
LWL-10km
57-1000027-02
XBR-000153/XBR-000172(8-pack)
ELWL-25km
57-0000080-01
XBR-000174(1-pack)
10G FC SFP+
SWL
57-1000114-01
XBR-000218(1-pack)
LWL-10km
57-1000115-01
XBR-000217(1-pack)
SWL
57-1000492-01
XBR-000418(1-pack)
LWL-10km
57-1000493-01
XBR-000417(1-pack)
16G FC SFP+
SWL
57-0000088-01
XBR-000192/XBR-000193(8-pack)
SWL
57-1000487-01
XBR-000492/XBR-000493(8-pack)
LWL-10km
57-0000089-01
XBR-000198/XBR-000199(8-pack)
LWL-10km
57-1000488-01
XBR-000498/XBR-000499(8-pack)
ELWEL-25km
57-1000262-01
XBR-000258(1-pack)
ELWEL-25km
57-1000489-01
XBR-000458(1-pack)
4x16G FC QSFP+
SWL
57-1000294-01/02
XBR-000245(1-pack)
SWL
57-1000267-01
XBR-000232(1-pack)
2km
57-1000310-01
XBR-000255(1-pack)
32G FC SFP+
SWL
57-1000333-01
XBR-000212/XBR-000213(8-pack)
SWL
57-1000485-01
XBR-000412/XBR-000413(8-pack)
LWL-10km
57-1000332-01
XBR-000238/XBR-000239(8-pack)
LWL-10km
57-1000486-01
XBR-000438/XBR-000439(8-pack)
ELWL-25km
57-1000355-01
XBR-000278(1-pack)
ELWL-25km
57-1000494-01
XBR-000478(1-pack)
4x32G FC QSFP+
SWL
57-1000351-01
XBR-000275(1-pack)
SWL
57-1000490-01
XBR-000475(1-pack)
2km
57-1000480-01
XBR-000285(1-pack)
Ethernet QSFP+
40GBASE-SR4 or 4x10GbE
57-1000129-01
XBR-40G-SR4-INT-0286
40GbE BiDi
57-1000339-01
XBR-40G-SR-BIDI-0287
100GBASE-SR4 or 4x25GbE
57-1000326-01
XBR-100G-SR4-0288
PRODUCT FEATURES
Brand |
Brocade |
Place of origin |
Philippines
|
Condition |
New |
Form Factor |
SFP+ |
Wavelength: |
1310nm |
Distance |
10km |
Data Rate (max) |
16Gb/s |
Diagnostics |
Digital |
Voltage Supply |
3.3--5v |
Connector |
Dual LC |
Warranty |
1 year |
Certificate |
CE , FCC, RoHs |
DDMI |
Yes |
Time of delivery |
Within 24 hours |
Package |
8 pcs/anti-static box |
prev :
Used Original Brocade 57-1000012-01 XBR-000147 8G SW Fibre Channel 850nm SFP Transceiver Brocade DCX ,5300,5100next :
Used Original Brocade 57-1000088-01 XBR-000193 SW 16G sfp+ Optical Modules Switch Brocade DCX 8510,6520,6510,6505,7840The SFP transceivers are high performance,Brocade XBR-000139 XBR-000141 XBR-000158 57-1000013-01 Compatible SFP 4.25G 850nm 550m Fibre Optic for Brocade DCX,5300,5100,300,Encryption,7800
TOP-SFP+-16G-SW Compatible With Brocade XBR-000192,XBR-000193,57-0000088-01,DCX 8510,6520,6510,6505,7840 Switch,optical transceivers are designed for 16Gb/s serial optical interfaces.Please read more on our web.
Brocade 10G-SFPP-SR 57-0000075-01 XBR-000180 XBR-000218 XBR-000181 optical transceivers are designed for 10Gb/s serial optical interfaces for data communications with multimode fiber (MMF) Please read and check it.
Brocade 57-1000080-01/XBR-000174 8Gbps EL 1310nm 25km optical transceivers are designed for 8Gb/s serial optical interfaces for data communications with multimode fiber (MMF) Please read and check it.
Brocade XBR-000192,XBR-000193,57-0000088-01 for DCX 8510,6520,6510,6505,7840 Switch,optical transceivers are designed for 16Gb/s serial optical interfaces.Please read more on our web.
Brocade 57-1000012-01 XBR-000147/XBR-000148/XBR-000159 for DCX ,5300,5100,300,encryption,7800 Switch,optical transceivers are designed for 8Gb/s serial optical interfaces.Please read more on our web.
Brocade XBR-000139 XBR-000141 XBR-000158 XBR-000097 57-1000013-01 SFP 4.25G 850nm 550m Fibre Optic for Brocade DCX,5300,5100,300,Encryption,7800 Switch,optical transceivers are designed for 4.25Gb/s serial optical interfaces.Please read more on our web.
Brocade XBR-000143 XBR-000142 57-1000014-01 SFP 4.25G 1310nm 4km Fibre Optic for Brocade DCX,5300,5100,300,Encryption,7800 Switch,optical transceivers are designed for 4.25Gb/s serial optical interfaces.Please read more on our web.
