Juniper Compatible XFP BIDI 1490/1550nm 100km 10G Bidirectional Fiber Optic Transceiver

XFP BIDI
new products

XFP BIDI 10G Fiber Optic Transceiver
XFP BIDI 10G Fiber Optic Transceiver XFP BIDI 10G Fiber Optic Transceiver XFP BIDI 10G Fiber Optic Transceiver XFP BIDI 10G Fiber Optic Transceiver

Juniper Compatible XFP BIDI 1490/1550nm 100km 10G Bidirectional Fiber Optic Transceiver

TOPSTAR's TOP-BIDI-XFP-100A/B transceivers are designed for 10G Ethernet 10G BASE-LR/LW per 802.3ae and 10G SOI OC-192/SDH STM-64, and it can support data-rate from 9.953Gb/s to 11.1Gb/s. Digital diagnostics are avail-able via I2C interface as specified in the XFP MSA. The transceiver designs are optimized for high performance and cost effective to supply customers the best solutions for data-com and telecom applications.

  • item no.:

    TOP-BIDI-XFP-100A/B

  • lead time:

    5-6 working days

  • product orgin:

    China

  • brand:

    Top-Trans

  • shipping port:

    Shenzhen

  • payment:

    ex-w

  • Warranty:

    3 Years

  • Condition:

    New

  • Temperature:

    0℃~70℃/ -5℃~85℃/ -20℃~85℃

  • Data Rate:

    10G

  • Distance:

    100km

  • Wavelength:

    1490/1550nm

  • Connector:

    LC
contact now
product details

Juniper Compatible XFP BIDI 1490/1550nm 100km 10G Bidirectional Fiber Optic Transceiver


SMF 10G SFP+ EZR 1550nm Ultra Long 100km Transceiver

10G SFP+ EZR 1550nm Transceiver




PRODUCT FEATURES

XFP MSA package with single LC connector

Typical bidi 1490/1550nm and 1550nm/1490nm for commission

APD receiver for high sensitivity

Hot pluggable

Support 9.95Gb/s to 11.1Gb/s bit rates

Digital Diagnostic Monitor Interface

Very low EMI and excellent ESD protection

+3.3V single power supply

Below <1.5w power consumption

operating temperature range 0°C to 70°C

No reference clock requirement


APPLICATIONS

10GBASE-BX 10.3125Gb/s Ethernet

10GBASE-BX 9.953Gb/s Ethernet

SONET OC-192 &SDH STM I-64.1


STANDARD

XFP MSA Compliant

SFF-8472 reversion 9.5 compliant

IEEE802.3-2005 compliant

Telcordia GR-468-CORE compliant

FCC 47 CFR Part 15,Class B compliant

FDA 21 CFR 1040.10 and 1040.11,class1 compliant

RoHS compliant


Professional Service

Fully testing in Error Detector/ Industrial Oven/ Agilent Oscilloscope/ Digitizer/ WaveRunner etc specialist testing equipment before shipment.



OEM& ODM:

Customized label and package , OEM and ODM service offered
