BR-6510DC-24-8G-R Brocade 6510 SAN Switch DC Power 24P 8GB SWL

Product Description:The Brocade 6510 Switch meets thedemands of hyper-scale, private cloud storage environments by delivering

market-leading Gen 5 Fibre Channel technology and capabilities that support highly virtualized environments; Leverages Brocade Fabric Vision technology’s powerful monitoring, management, and diagnostic tools to simplify administration, increase uptime, and reduce costs;

item no.:
BR-6510DC-24-8G-R
Warranty:
1 Year
Condition:
New
Data Rate:
8G

contact now

product details

Brocade Communication BR-6510DC-24-8G-R 6510 Switch DC Power 24P 8GB SWL

The hyper-scale and private cloud storage environments demand Brocade 6510 Switch

Product Description:The Brocade 6510 Switch meets thedemands of hyper-scale, private cloud storage environments by delivering

Main features	Systems Architecture
AC Power consumption	110 W with all 48 ports populated with16 Gbps SWL optics 72 W for empty chassis with no optics
Scalability	Full-fabric architecture with a maximum of 239 switches
Certified maximum	6000 active nodes; 56 switches, 19 hops in Brocade Fabric OS® fabrics; larger fabrics certified as required
Management access	10/100 Mbps Ethernet (RJ-45), in-band over Fibre Channel, serial port (RJ-45), and one USB port
ISL Trunking	Frame-based Trunking with up to eight 16 Gbps ports per ISL trunk; up to 128 Gbps per ISL trunk. Exchange-based load balancing across ISLs with DPS included in Brocade Fabric OS.
USB	One USB port for system log file downloads or firmware upgrades
Vibration	Operating: 0.5 g sine, 0.4 grms random, 5 Hz to 500 Hz Non-operating: 2.0 g sine, 1.1 grms random, 5 Hz to 500 Hz
Power supply	Dual, hot-swappable redundant power supplies with integrated system cooling fans

A Building Block for Virtualized, Private Cloud Storage The Brocade 6510 provides a critical building block for today’s highly virtualized, private cloud storage environments. It simplifies server virtualization and Virtual Desktop Infrastructure (VDI) management while meeting the high throughput demands of Solid State Disks (SSDs). The Brocade 6510 also supports multitenancy in cloud environments through Virtual Fabrics, Quality of Service (QoS), and fabric based zoning features.

The Brocade 6510 enables secure metroextension to virtual private or hybrid clouds with 10 Gbps Dense Wavelength Division Multiplexing (DWDM) link support, as well as in-flight encryption and data compression over ISLs. Organizations can have up to four ports at 8 Gbps and up to two at 16 Gbps of in-flight encryption and data compression per Brocade 6510 Switch. The switch also features on-board data security and acceleration, minimizing the need for separate acceleration appliances to support distance extension. Internal fault tolerant and enterprise-class RAS features help minimize downtime to support mission-critical cloud environments.

FAQ

Q1. What Brocade optical transceivber can be used on this Brocade 6510 switch?

A1: 57-0000088-01 XBR-000192 XBR-000193 etc Brocade 4G 8G 16G whole series optical modules can be used;

Q2. How does your company do regarding quality control?

A2: All our Brcoade switch were from formal channels, and we only sell original type products for the past 16 years;

Q3. What are the warranty of this switch?

A3: 1 year for repair;

DS-6610B-L Series
DS-6610B-L models are functionally equivalent to the DS-6610B switches above, however; the “-L” models include a unique Limited Lifetime Warranty. The Limited Lifetime Warranty remains in effect until the end of support life for the DS-6610B-L -switch. The DS-6610B-L switches also include an “-EP” fully populated with 24 32Gb/s SFPs and the Enterprise Package
