TOP QSFP-100G-LR4-D Compatible 100GBASE-LR4 and 112GBASE-OTU4 QSFP28 Dual Rate 1310nm 10km Transceiver Module

TOP QSFP-100G-LR4-D Compatible 100GBASE-LR4 and 112GBASE-OTU4 QSFP28 Dual Rate 1310nm 10km Transceiver Module

  • item no.:

    100G QSFP28 LR4 10km
  • brand:

    Top-Trans
  • Warranty:

    1 Year
  • Condition:

    New
  • Temperature:

    0 to 70°C
  • Data Rate:

    Dual Rate 103.1Gbps and 112Gbps
  • Distance:

    10km
  • Wavelength:

    1310nm
  • Connector:

    LC
product details

Product Details

Cisco Compatible QSFP-100G-LR4-D Vendor Name FS
Form Type QSFP28 Data Rate Dual Rate 103.1Gbps and 112Gbps
Wavelength 1310nm Max Cable Distance 10km
Connector LC duplex Transmitter Type DML 1310nm
Cable Type SMF DDM/DOM Supported
TX Power -4.3~4.5dBm Receiver Sensitivity <-10.6dBm
Protocols 100G Ethernet, MSA Compliant Commercial Temperature Range 0 to 70°C (32 to 158°F)
