Original Used Avago AFCT-57G5MZ 32GFC SFP28 for Single-Mode Optical Fiber Digital Diagnostic SFP, 1310nm, 32G/16G/8G Low Voltage (3.3 V) Fibre Channel Optical Transceiver

item no.:
32G SFP28 LR 10km
brand:
AOI
Warranty:
1 Year
Condition:
New
Temperature:
0-70
Data Rate:
32G
Distance:
10km
Wavelength:
1310nm
Connector:
LC

contact now

product details

Original Used Avago AFCT-57G5MZ 32GFC SFP28 for Single-Mode Optical Fiber Digital Diagnostic SFP, 1310nm, 32G/16G/8G Low Voltage (3.3 V) Fibre Channel Optical Transceiver

Features

Compliant to RoHS directives
1310nm Distributed Feedback Laser (DFB)
Class 1 eye safe per IEC60825-1 and CDRH
Wide temperature range (0°C to 70°C)
LC duplex connector optical interface conforming to
ANSI TIA/EIA604-10 (FOCIS 10A)

Diagnostic features per SFF-8472 “Diagnostic Monitoring Interface for Optical Transceivers”
Real time monitoring of:
Transmitter average optical power
Received average optical power
Laser bias current
Temperature
Supply Voltage
SFP+ mechanical specifications per SFF-8432
Pull Tab delatch mechanism
SFP+ compliant low speed interface
Fibre Channel FC-PI-6 compliant high speed interface
3200-M5-SN-S, 1600-M5-SN-S, 800-M5-SN-S
3200-M5E-SN-I, 1600-M5E-SN-I, 800-M5E-SN-I
3200-M5F-SN-I, 1600-M5F-SN-I, 800-M5F-SN-I

Fibre Channel FC-PI-6 compliant optical link distances

Specification
Lifecycle Active
Distrib. Inventory Yes
Connector Type LC
Data Rate (Gb/s) 28.05
Data Rate Group 25G-32G
Form Factor SFP28
Fiber Type Singlemode
Nominal Optical Wavelength (nm) 1310
Markets Storage
Maximum Distance (m) 10000
