Original Used Avago AFBR-8422IDZ CFP2 850nm 100GBASE-SR10 Compliant Pluggable 100G Ethernet Optical Transceiver

Original Used Avago AFBR-8422IDZ CFP2 850nm 100GBASE-SR10 Compliant Pluggable 100G Ethernet Optical Transceiver

  • item no.:

    100G CFP2 SR 100m
  • brand:

    AOI
  • Warranty:

    1 Year
  • Condition:

    New
  • Temperature:

    0-70
  • Data Rate:

    100G
  • Distance:

    100m
  • Wavelength:

    850nm
  • Connector:

    LC
product details

Original Used Avago AFBR-8422IDZ CFP2 850nm 100GBASE-SR10 Compliant Pluggable 100G Ethernet Optical Transceiver

Features


Links up to 100 m using OM3 fiber and 150 m using OM4 fiber
CFP2 Power Dissipation Class 2 with CDRs in bypass. CDRs are bypassed for lower power dissipation by default.
CFP2 Power Dissipation Class 3 with CDRs ON
Proven High Reliability 850 nm technology: Avago VCSEL array transmitter and Avago PIN array receiver
Compliant to 100 GbE specifications 802.3ba(100GBase-SR10 and CPPI) up to 100 m OM3 and 150 m OM4 fiber
Compliant to 40GbE specifications 802.3ba (40GBaseSR4 and XLPPI) up to 100 m OM3 and 150 m OM4 fiber
Compatible with 10GE SR specifications per 802.3ae (10GBASE-SR) up to 100 m OM3 fiber
OTU4 Support at 11.18 Gb/s per channel
CFP2 10x10Gbit/s Host Pin Map
Class 1 eye safe per IEC60825-1 and CDRH
Wide case temperature range (0°C to 70°C)
Utilizes standard 24 lane optical fiber with MTP® (MPO) optical connector for high density and thin, lightweight cable management
Diagnostic features per CFP2 using MDIO. Real time monitoring of:
Transmitter average optical power
Received average optical power
Laser bias current
Temperature
Supply Voltage
Host Lane Loopback (eLoop) and Network LaneLoopback (oLoop) functionality
Integrated CDRs on each transmit and receive lane
Support CDB (Common Data Block) per CFP MSA MIS Version 2.2[1]
CFP Management Interface Specification Version 2.2[1]
CFP2 Hardware Specification Revision 1.0[2]

Compliant to RoHS directives


Specification
Lifecycle Active
Distrib. Inventory Yes
Connector Type MPO
Data Rate (Gb/s) 100
Data Rate Group 100G-300G
Form Factor CFP2
Fiber Type Multimode
Nominal Optical Wavelength (nm) 850
Markets Cloud Data Center,Enterprise,Telecom
Maximum Distance (m) 100
Transceiver Evaluation Kits AVG_Product_C:1211241365765
