Compatible FTLX1472M3BCL 10Gb/s 2/10km Single Mode Multi-Rate 10G SFP+ LR Optical Transceiver

Finisar’s FTLX1472M3BCL 10Gb/s Enhanced Small Form Factor Pluggable SFP+ transceivers are designed for use in 10-Gigabit, multi-rate links up to a maximum 10km over G.652 single mode fiber. They are compliant with SFF-8431 , SFF-8432 , ITU-T G.693 VSR2000-2R1, SDH I-64.1 and OTN P1I1-2D1 (up to 2km), IEEE 802.3ae 10GBASE-LR/LW and 10G Fiber Channel 1200-SM-LL-L (up to 10km). Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF8472 . The FTLX1472M3BCL transceivers utilize internal clock and data recovery (CDR) units on the transmitter and the receiver chains for SONET/SDH jitter compliance and to enhance the signal integrity on XFP XFI-like host card designs. The optical transceiver is compliant per the RoHS Directive 2011/65/EU. See Finisar Application Note AN-2038 for more details.


  • item no.:

    FTLX1472M3BCL
  • lead time:

    2-3 working days
  • product orgin:

    Malaysia
  • brand:

    Finisar
  • shipping port:

    Shenzhen
  • payment:

    ex-w
  • Warranty:

    1 Year
  • Condition:

    Original
  • Temperature:

    -5°C-75°C
  • Data Rate:

    10G
  • Distance:

    10km
  • Wavelength:

    1310nm
  • Connector:

    LC
product details


FTLX1472M3BCL 10Gb/s 2/10km Single Mode Multi-Rate 10G SFP+ LR Optical Transceiver


Finisar 10G SFP+ FTLX1472M3BCL transceiver, LC, 1310, 10km


Product Fectures

Brand Finisar
Original Place Malaysia
Form Factor SFP
Part Number FTLX1472M3BCL
Datarate 10G
Wavelength 1310nm
Distance 10km
Connector LC Connector
Temperature -5-75°C
Warranty
1 year

FTLX1472M3BCL

Details


Hot-pluggable SFP+ footprint

Supports 8.5Gb/s and from 9.95 to 11.3Gb/s bit rates

Power dissipation < 1.5W

RoHS-6 compliant (lead-free)

Commercial temperature range -5°C to 75°C

Single 3.3V power supply

Maximum link length of 10km

Un-cooled 1310nm DFB laser

Receiver limiting electrical interface

Duplex LC connector

Built-in digital diagnostic functions







APPLICATIONS


10G NRZ SONET VSR2000-2R1, SDH I-64.1, OTN P1I1-2D1 

10G Ethernet 10GBASE-LR/-LW

10G Fibre Channel 1200-SM-LL-L

G.709 OTU 1e/2/2e FEC bit rates

8.5Gb/s Fibre Channel
