Compatible Finisar FTLF1519P1xCL 1000BASE-ZX and 2G Fibre Channel (2GFC) 80km SFP Optical Transceiver
item no.:
2G SFP LC 80kmbrand:
FinisarWarranty:
3 YearsCondition:
NewTemperature:
-10-70Data Rate:
2.125 Gb/sDistance:
80kmWavelength:
1550nmConnector:
LCProduct Description：
Distance:90 km
Data Rate (max):2.125 Gb/s
Protocol:Optical Gigabit Ethernet Compliant 1x Fibre Channel Compliant 2x Fibre Channel Compliant Wireless CPRI Compliant
Low End Case Temperature (°C):-10
High End Case Temperature (°C):70
Diagnostics:Digital
Transmitter:DFB Laser
Receiver:PIN
Voltage Supply:3.3
Connector:LC
Wavelength:1550nm
Product Feature：
Up to 2.125Gb/s bi-directional data links
Hot-pluggable SFP footprint
Built-in digital diagnostic functions
Uncooled 1550nm DFB laser transmitter
Duplex LC connector
RoHS compliant and Lead Free
Metal enclosure, for lower EMI
Single 3.3V power supply
Up to 80 km on 9/125μm SMF
Low power dissipation <700mW typical
Extended operating temperature range: -10°C to 70°C
prev :
Compatible Finisar FTLF1519P1xNL 1000BASE-ZX and 2G Fibre Channel (2GFC) 80km SFP Extended Temperature Optical Transceivernext :
Compatible Finisar FTLF1518P1BTL 1000BASE-ZX and 1G Fibre Channel (1GFC) 80km SFP Optical Transceiver
Used Original Finisar FTLF1621P1xCL 1550nm 80km ZR 2G Optical Modules
Finisar FTLF1621P1xCL (80km ZR 2G)Small Form Factor Pluggable (SFP) optical transceivers are compatible with the SFP Multi-Sourcing Agreement (MSA). They comply with SONET OC-48 LR-2 (SDH STM L-16.2) standards, Gigabit Ethernet as specified in IEEE Std 802.3 and Fibre Channel FC-PI 13.0. They(2G Optical Modules) are compatible with SONET OC-12 SR and SONET OC-3 standards. Digital diagnostics functions are available via the 2-wire serial bus specified in the SFP MSA.
Compatible Original Finisar FWLF1523P1x51 1550nm 80km ZX 155 MB SFP modules
Finisar FWLF1523P1x51 Small Form Factor Pluggable (SFP) transceivers provide a reliable solution for 1511nm, point-to-point, 155Mb/s Optical Supervisory Channel (OSC) applications, outside the band of the transmitted signal. 1550nm 80km ZX 155 MB Modules are compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA), as well as with SONET and SDH standards at OC-3 LR-2/STM L-1.2 and Fast Ethernet applications. Digital diagnostics functions are available via the 2-wire serial bus specified in the SFP MSA. 155M ZX SFP Modules are RoHS compliant and lead-free per Directive 2011/65/EU and Finisar Application Note AN-2038.
Compatible Original Finisar FWLF15197Dxx 80km ZX 1G CWDM Optical Modules
Finisar's FWLF15197Dxx CWDM Small Form Factor Pluggable (SFP) optical transceivers are designed for operation in Metro Access Rings and Point-to-Point networks using Gigabit Ethernet and Fibre Channel networking equipment.The 1G CWDM Optical Modules are available in eight different CWDM wavelengths. Digital diagnostics functions are available via two-wire serial bus. In addition, the 80km CWDM Optical Modules comply with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA). The optical transceiver is compliant per RoHS Directive 2011/65/EU.
Original Finisar FWLF16197Dxx Compatible 100km 1.25G CWDM Optical Transceiver
Finisar FWLF15197Dxx CWDM Small Form Factor Pluggable (SFP) 1.25G CWDM Optical Transceiver is designed for operation in Metro Access Rings and Point-to-Point networks using Gigabit Ethernet and Fibre Channel networking equipment. The 100km 1.25G CWDM are available in eight different CWDM wavelengths. Digital diagnostics functions are available via two-wire serial bus. In addition, the 100km CWDM Optical Transceivers comply with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA). The optical transceiver is compliant per RoHS Directive 2011/65/EU.
Compatible Finisar FTLX6814MCC 1600ps/nm 80km Tunable DWDM XFP Optical Transceiver
This product is a 10Gb/s XFP DWDM transceiver module,which is 10GBASE 40KM DWDM XFP. Finisar FTLX6814MCC transceiver has a maximum reach of 80km at 10.5 Gb/s data rate.
Compatible Original Finisar FWLF15217Dxx 2G 1550nm CWDM 50km Mini-GBIC SFP Transceiver Module
Finisar FWLF15217Dxx CWDM 50km 2G SFP transceivers are designed for operation in Metro Access Rings and Point-to-Point networks using SONET, Gigabit Ethernet and Fibre Channel networking equipment. Finisar 50km 2G CWDM are available in eight different CWDM wavelengths and comply with ITU CWDM standard. Digital diagnostics functions can be accessed via an I2C serial bus. In addition, the transceivers comply with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA) are RoHS and lead-free compliant per Directive 2011/65/EU and Finisar Application Note AN-2038.
Compatible Finisar FWLF1621P2Txx 1550nm 2.67G CWDM 50km High Density CWDM Transceivers Gigabit Ethernet and Fibre Channel Modules
Finisar FWLF1621P2Txx CWDM Small Form Factor Pluggable (SFP) transceivers are designed for operation in Metro Access Rings and Point-to-Point networks using SONET, Gigabit Ethernet Modules and Fibre Channel Modules networking equipment in environments where temperatures are not controlled. CWDM 50km 2.67G SFP is available in eight different CWDM wavelengths and complies with ITU CWDM standard. Digital diagnostics functions can be accessed via an I2C serial bus. In addition, High Density CWDM Transceivers comply with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA) are RoHS and lead-free compliant per Directive 2011/65/EU and Finisar Application Note AN-2038.
Compatible Finisar FWLF1621P2Txx ZX CWDM SFP 80km 2.67G Gigabit Ethernet Optical Transceivers
Finisar FWLF1621P2Txx CWDM Small Form Factor Pluggable (SFP) ZX CWDM SFP transceivers are designed for operation in Metro Access Rings and Point-to-Point networks using SONET, Gigabit Ethernet and Fibre Channel networking equipment in environments where temperatures are not controlled. CWDM 80km 2.67G SFP is available in eight different CWDM wavelengths and comply with ITU CWDM standard. Digital diagnostics functions can be accessed via an I2C serial bus. In addition,1550nm 2.67G CWDM Optical Transceivers comply with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA) are RoHS and lead-free compliant per Directive 2011/65/EU and Finisar Application Note AN-2038.
