5m LC UPC To SC UPC Duplex OS2 Single Mode PVC3.0mm Fiber Patch Cable

MTP stands for multi-fiber termination push-on connector, which is a registered trademark of US Conec. MTP Wiki defines it as a brand name for a version of MPO connectors with improved specifications.

item no.:
10m SC UPC to SC UPC
brand:
Top-Trans
Warranty:
1 Year
Condition:
New
Data Rate:
100G
Distance:
10m

contact now

product details

5m LC UPC To SC UPC Duplex OS2 Single Mode PVC3.0mm Fiber Patch Cable

High Quality and Cost-effective 9/125μm Single Mode Bend Insensitive Fiber Optic Cable

The LC/UPC-SC/UPC Fiber Patch Cord Duplex SM G.657.A1 2.0mm 1m Yellow (Part number: PT-SM-LCU-SCU-DX-5M) from Topstar is a Duplex patch cord with LC/UPC connector at one side and a SC/UPC connector at the other one. Fiber patch cords are a type of cables that have two connectors on both ends. Optic patch cords can come in simplex (1 fiber), duplex (2 fibers) or in MPO (12 fibers). The connectors on both sides of the patch cord, allow it to be quickly connected to another device such as an optical switch or other telecommunications/computer device.

Singlemode
Polishing UPC
Return loss ≥ 55 dB (unmated), >60 dB (mated)
Insertion loss ≤ 0,25 dB (Grade B1)
Ferrule material Ceramic (zirconia)
Ferrule diameter 1.25 mm / 2.5 mm
Insertion / extraction cycles Min. 1000

Cable Mechanical Properties

Cabled optical fiber OS2
Nominal diameter core / sheath 9 / 125 μm
Color Yellow
Outer diameter 1.6 mm to 3 mm
Sheath material LSZH, UL-94 V0
Bending radius (static) 45 mm
Temperature range -20°C +70°C
Attenuation @ 850 / 1300 nm (dB/km) ≤ 3,2 / ≤ 0,8
Attenuation @ 1310 / 1383 / 1550 nm (dB/km) ≤ 0,4 / ≤ 0,4 / ≤0,4

Fiber Grade	G.657.A1 (Compatible with G.652.D)
Fiber Mode	OS2 9/125μm
Wavelength	1310/1550nm
Cable Diameter	3.0mm
Min. Bend Radius (Fiber Core)	10mm
	Min. Bend Radius	(Fiber Cable)	10/5D (Dynamic/Static)
Attenuation at 1310 nm	0.36 dB/km
Attenuation at 1550 nm	0.22 dB/km
Cable Jacket	PVC
Polarity	A (Tx) to B (Rx)
Fiber count	Duplex
Storage Temperature	-40~80°C

Fiber Type	OM4 50/125um
Wavelength	850/1300nm
10G Ethernet Distance	400m at 850nm
40/100G Ethernet Distance	150m at 850nm
Polish Type	UPC to UPC
Minimum Bend Radius	7.5mm
Attenuation at 850nm	≤2.3 dB/km
Attenuation at 1300nm	≤0.6 dB/km
Installation Tensile Load	66N
Tensile Strength (Long/Short Term)	80N/240N

Premium multimode fiber optic cabling for transmitting 40/100 Gb data and voice signals over short distances. Designed for high-density connections between network equipment in telecom rooms and data centers.

Push/pull tab connectors install/remove with one hand

12-fiber MTP/MPO connectors with 12x density of SC connectors

100% tested for low insertion loss and back reflection
Base-8 Fiber compatible with both QSFP+ 40GBASE-SR4 and QSFP28 100GBASE-SR4 connections
50/125 OM4-rated multimode fiber
Aqua color for easy OM4 identification

MTP/MPO Connectors with Push/Pull Tabs
12-fiber female connectors 12 times denser than SC connectors
Push/pull tab connectors easy to install and remove with one hand
100% tested for low insertion loss and back reflection

Error-Free Signal Transfer
50/125 duplex glass fiber construction
Plenum-rated jacket perfect for ceilings, walls and ducts
